Full-automatic valve bag packing machine

The automatic valve bag packing machine is an automatic bagging quantitative packing machine designed for powder or ultra-fine powder materials with low bulk density, strong air affinity, excellent or poor self-flow. It is mainly divided into: impeller type packing machine, spiral type packing machine, air feeding packing machine.

Classification:

Automatic valve bag packing machine

Key words:

Full-automatic valve packing machine

Automatic valve packaging machine

E-mail:

channingchanning11@gmail.com

Inquiry

Product Details

The full-automatic valve bag packing machine is designed for various powder or ultra-fine powder materials with low stacking density, strong air affinity, and excellent or extremely poor self-flow. It is an automatic bagging quantitative packing machine. It is mainly divided into: impeller type packaging machine, spiral type packaging machine, air feeding packaging machine.
Features
Efficient and environmentally friendly new feeding machine, choice of feeding method.
Fully automatic bag picking, bag opening, and bag-on mechanism.
Automatic heat sealing, perfectly coordinated with the production line.
Technical parameters

Machine Model	SW-AT-VBM-LX	DSC-QF-25/50
Automatic mode	Automatic valve packing machine	Manual bagging machine
Packaging range	10-50KG	20-50KG
Packing speed	120-240 bags/hour	120-240 bags/hour
Packing	Powder Particle mixture	Powder Particle mixture
Weighing accuracy	0.2%F、S	0.2%F、S
Packaging material	Packing bag	valve pocket
Feeding mode	Optional according to material	Optional according to material
Compressed air	0.5-0.6MPa，1m³/min	0.4-0.8MPa，0.3m³/min
Power Supply	9kw/h，AC380V 50Hz	2.2kw/h，AC380V 50Hz
